BSGE1500
|
Engine model |
BS156FE(BS156FDE/P) |
|||
| Engine Type | single-cylinder,forced air-cooled 4-stroke,OHV,25°,tilt | |||
| Rated output(kw) | 0.8 | |||
| Max output(kw) | 1 | |||
| Rated voltage | 230 | |||
| Rated frequency | 50/60 | |||
| Power factor(cos￠) | 1.0 | |||
| Continuous running time(h) | 10 | |||
| Displacement(ml) | 98.0 | |||
| Ignition system | T.C.I. | |||
| Fuel tank capacity(L) | 6 | |||
| Lube oil capacity(L) | 0.35 | |||
| Starting system | Recoil/Electric | |||
| Package dimensions(Lx W x H) (mm) | 475x380x450 | |||
| N.W/G.W(KG) | 29/30.5 | |||
| Loading quantity(20GP/40GP/40HQ) | 360/720/864 | |||
